1.Product Introduction
SCA-10 Lub tshuab ua dej txias yog qhov ua tau zoo thiab lub zog txuag hluav taws xob ua kom muaj cua txias tsim los ua kom tau raws li qhov xav tau txias dua. Nws muaj peev xwm ua kom txias txias thiab txhim khu kev qha Cov chaw tsim khoom, tshuaj lom neeg, khoom siv hluav taws xob, khoom noj khoom haus, lub tshuab chiller tau nruab nrog cov cuab yeej txias txias, tuaj yeem ua kom ruaj khov, ua kom txias txias, ua kom muaj kev pab cuam lub neej ntawm cov cuab yeej, txhim kho kev tsim khoom. Kev siv cov tshuab tub yees siab heev thiab muaj kev ntseeg siab los xyuas kom muaj kev ua kom txias txias, ceev ceev, kom tau raws li qhov xav tau ntawm cov khoom txias txias. Nruab nrog lub zog txuag hluav taws xob tswj qhov system, hloov kho lub sijhawm ua haujlwm raws li qhov tseeb load, zoo txo hwj chim noj thiab txo cov nqi khiav lag luam. Cov txheej txheem dej txias, los ntawm cov cua txias ntauwd los yog pas dej ua ke los muab cov dej txias, kom ntseeg tau tias cov nyhuv txias yog qhov ruaj khov dua, tshwj xeeb tshaj yog tsim rau kev ua haujlwm mus ntev. Kev siv cov khoom siv ruaj khov thiab cov txheej txheem tsim precision los xyuas kom meej tias cov cuab yeej tseem tuaj yeem ua haujlwm ruaj khov hauv ib puag ncig insomnia, txo qhov zaus ntawm kev saib xyuas. Nruab nrog kov npo tswj vaj huam sib luag thiab cov chaw taws teeb saib xyuas muaj nuj nqi, tsis tas yuav khiav lag luam, saib xyuas lub sijhawm ua haujlwm, tuaj yeem tswj xyuas thiab kho. Kev siv lub suab nrov zoo, tsis muaj suab nrov thaum lub sijhawm ua haujlwm, haum rau ib puag ncig uas yuav tsum muaj suab nrov nruj.
2.Product Parameter
|
Technical Parameters ntawm Dej Txias Scroll Chiller (Ⅰ) |
|||||||
|
Qauv |
SCW-05 |
SCW-08 |
SCW -10-Ⅱ |
SCW -15-Ⅲ |
SCW -20-Ⅱ |
SCW -25-Ⅱ |
|
|
Lub tub yees muaj peev xwm (Kcal/lKw/Rt/h) |
15093 Kcal 17.55 KW TSI 4, 99 ttk |
24148 Kcal 28.08 KWG 7, 98 ttk |
30 186 kcal 35.1 KW UA 9, 98 ttk |
4 5279kv 52.65 KW UA 14.97 Nws |
6 0372kv 70.2 kWm 19.96 Nws |
7 5465k 87.75 kWm 24.95 Nws |
|
|
Cov tub yees |
R407C |
||||||
|
compressor zog (Hp) |
5 |
8 |
10 |
15 |
20 |
25 |
|
|
Circulating twj tso kua mis zog (Hp) |
0.75 |
1 |
1/1.5 |
1.5/2 |
1.5/2 |
2/3 |
|
|
Piping ntawm dej txias system |
cev diam |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Dej ntws (m³ / h) |
3.4 |
5.5 |
6.85 |
9.3 |
12.7 |
15.1 |
|
|
Chilled drainage piping |
cev diam |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Dej ntws (m³ / h) |
2.74 |
4.27 |
4.27 |
8.59 |
8.59 |
14.55 |
|
|
muab hluav taws xob |
AC380V50HZ3PH 3 AC440V50HZ3PH 3 AC 220V 60HZ 3PH |
||||||
|
Nqe lus piav qhia: 1.Lub peev xwm ua kom txias yog raws li evaporating kub: 7 degree, condenser kub: 40 degree, refrigerant: R407C, txias dej kub: 32-37 degree 2.Optional refrigerant: R134A / R404A / R22 |
|||||||
|
Technical Parameters ntawm Dej Txias Scroll Chiller (Ⅱ) |
||||||
|
Qauv |
SCW -30-Ⅱ |
SCW-40 |
SCW-50 |
SCW-60 |
SCW-80 |
|
|
Lub tub yees muaj peev xwm (Kcal/lKw/Rt/h) |
9 0558k PEB 105.3 KW 29.94 Nws |
120744 Kcal 140.4 KW TSI 39.92 Nws |
150930 Kcal 175.5 KW TSI 4 9.9 ttk |
181116 Kcal 210.6 KW TSI 5 9.88 ttk |
241488 Kcal 280.8 KW TSI 7 9.84 ttk |
|
|
Cov tub yees |
R407C |
|||||
|
compressor zog (Hp) |
30 |
40 |
50 |
60 |
80 |
|
|
Circulating twj tso kua mis zog (Hp) |
3/4 |
40HP thiab siab dua yog teeb tsa raws li cov neeg siv khoom xav tau |
||||
|
Piping ntawm dej txias system |
cev diam |
2.5" |
3" |
3" |
4" |
4" |
|
Dej ntws (m³ / h)
|
18.5 |
24.5 |
30.2 |
36.2 |
48.2 |
|
|
Chilled drainage piping |
cev diam |
2.5" |
3" |
3" |
4" |
4" |
|
Dej ntws (m³ / h) |
14.55 |
22.06 |
22.06 |
42.2 |
42.2 |
|
|
muab hluav taws xob |
AC380V50HZ3PH 3 AC440V50HZ3PH 3 AC 220V 60HZ 3PH |
|||||
|
Nqe lus piav qhia: 1.Lub peev xwm ua kom txias yog raws li evaporating kub: 7 degree, condenser kub: 40 degree, refrigerant: R407C, txias dej kub: 32-37 degree 2.Optional refrigerant: R134A / R404A / R22 |
||||||
3.Product feature thiab daim ntawv thov
- Txoj kev ua kom txias:
Lub tshuab ua dej txias: Kev siv cov dej txias ua qhov cua txias, los ntawm cov cua txias ntauwd los yog pas dej ua ke kom cov dej ntws tawm, tuaj yeem tshem tawm cov cua sov zoo dua, tsim nyog rau qhov chaw txias mus ntev.
Lub tshuab cua txias: Kev siv cua txias, feem ntau nrog lub kiv cua kom tshem tawm cov cua sov, haum rau kev thauj khoom me me los yog siv tsis tu ncua ntawm lub sijhawm.
- Combustion efficiency:
Dej txias: Vim tias qhov tshwj xeeb kub muaj peev xwm ntawm cov dej nce, qhov ua kom txias txias yog siab, thiab nws tuaj yeem tswj tau qhov txias txias hauv qhov kub thiab txias.
Cua txias: cuam tshuam los ntawm qhov kub thiab txias, qhov ua tau zoo yog txo qis hauv huab cua kub, thiab yuav tsum tau saib xyuas ntau dua.
- Kev them nyiaj yug thiab nqi:
Dej txias: Txawm hais tias kev nqis peev ntau dua, cov nqi ua haujlwm ntev feem ntau qis dua vim nws qhov ua kom txias dua thiab kev txuag hluav taws xob.
Lub tshuab cua txias: kev nqis peev tsawg, tab sis kev ua haujlwm mus sij hawm ntev tuaj yeem tsim lub zog siv ntau dua vim qhov txo qis ntawm kev ua kom txias.
- Maintenance thiab installation:
Lub tshuab ua dej txias: Cov dej txias yuav tsum tau kuaj xyuas tsis tu ncua, kev teeb tsa thiab kev saib xyuas yog qhov nyuaj, tab sis nws tsim nyog rau kev tsim khoom loj lossis cov khoom siv hauv ib puag ncig.
Cua txias: kev txhim kho yog qhov tsim nyog, kev saib xyuas yog qhov yooj yim, tab sis rau lub nra hnyav lossis qhov kub thiab txias ib puag ncig kev ua haujlwm tau txwv ntau dua.
4.Prodection cov ntsiab lus
|
|
|
|
|
|
5.Product tsim nyog
|
|
6.Kev xa khoom, kev xa khoom thiab kev pabcuam
- Cov qauv ntsuas rau peb cov khoom lag luam zoo hauv paus ua raws li cov txheej txheem kev qhia los ntawm tus neeg siv khoom, thiab peb yuav muab cov khoom lag luam tom qab tau txais kev pom zoo los ntawm cov neeg siv khoom, thaum siv zog ua kom ruaj khov thiab txhim kho kev ua tau zoo ntawm cov khoom zoo.
- Raws li tus neeg muag khoom, peb xyuas kom meej tias tag nrho cov khoom muab tau raws li tag nrho cov qauv kev cai lij choj thiab ua lub luag haujlwm rau cov khoom zoo. Thaum tsim nyog, peb yuav muab cov neeg siv khoom nrog cov ntaub ntawv ntxaws ntxaws, suav nrog cov ntaub ntawv tshuaj xyuas cov khoom thiab lwm yam ntaub ntawv tsim nyog.
- Peb cog lus tias txhua yam khoom siv los nrog 18- lub sijhawm lav, suav txij hnub xa khoom los ntawm peb lub Hoobkas.
- Nyob rau hauv cov ntaub ntawv ntawm cov khoom malfunctions, thov tam sim ntawd hu rau peb tus neeg muag khoom, thiab peb cov kev pab cuam yuav pib cov kev pab cuam hauv internet nyob rau hauv 4 teev kom txog thaum qhov teeb meem no tiav.
- Thaum lub sijhawm lav, kev hloov khoom seem yog dawb; sab nraum lub sijhawm lav, peb muab qhov tseem ceeb ntawm kev muab cov khoom seem ntawm tus nqi, nrog rau cov nqi thauj khoom yuav tsum tau them los ntawm tus neeg yuav khoom.
- Peb tuav cov khoom lag luam ntau ntawm cov khoom siv thiab cov khoom siv thoob plaws hauv lub xyoo thiab cog lus tias yuav muab kev pabcuam kev sib tham ib puag ncig (7x24 teev) kom ntseeg tau tias kev daws teeb meem sai ntawm cov cuab yeej tsis ua haujlwm thiab rov pib tsim khoom.
- Thaum lub sij hawm installation thiab commissioning txheej txheem, yog hais tias koj ntsib tej teeb meem, thov tham tam sim nrog peb tus account manager. Peb lub tuam txhab yuav xa cov kws tshaj lij los muab kev qhia hauv online, kom ntseeg tau tias koj pab neeg ua haujlwm muaj kev nkag siab zoo txog kev teeb tsa thiab kev ua haujlwm, tso lub hauv paus ruaj khov rau kev tu lub neej yav tom ntej.
7.FAQ
- Peb lub zog yog dab tsi?
Peb cov chillers tau txhim kho cov txheej txheem kev lag luam hauv cov ntsiab lus ntawm kev ua kom txias thiab lub zog ua haujlwm: lawv muaj 30% ntau dua li lawv cov phooj ywg. Tsis tas li ntawd, nrog tib lub zog compressor, peb cov khoom siv hluav taws xob zoo dua li cov khoom lag luam tub yees tau nce 30%. Nyob rau tib lub sijhawm, peb cov khoom raug nqi 10% qis dua kev lag luam, muab cov neeg siv khoom xaiv ntau thiab ntau dua.
- Dab tsi yog qhov txawv ntawm vortex thiab ntsia hlau?
Scroll tshuab tsis xav tau kev saib xyuas
Lub tshuab scroll yog tag nrho
Lub tshuab ntsia hlau yog semi-enclosed
